A-18617 Trough IRED LED PCB Assembly
o
o
LED6 LED?
00
LED3
00
o
LED2
Part Number
Designator
Description
5671-12731-00 LED1 - LED7
5791-12622-09 J1
Infra Red Diode
Connector, 9-pin Header Sq.
A-18618 Trough IRED Transistor PCB Assembly
o
Part Number
Designator
Description
5163-14114-00 Q1 -
07
5791-12622-09 J1
Infra Red Photo Transistor
Connector, 9-pin Header Sq.
