T.16 GOFER TEST CONTINUED •••
OPTO FAILURE: The software cannot read the Gofer Down opto switch associated with this
mechanism.
RAMP SW FAILURE: The software cannot read the Ramp Down microswitch associated with this
mechanism.
WARNING GOFER DISABLED: The Gofer may not be operating in game play because it was
disabled in the A2.12 or A2.13 adjustment(s).
T.17 WHEEL TEST
Use this test to check the orientation of the Wheel Award decal and check that the wheel motor is
operating properly.
Press Enter to begin the test. The test will then spin the wheel and make sure that the wheel
opto switches and the motor are functioning correctly. The display will then show what the game
believes to be the current wheel position.
You may turn the wheel by hand to check the alignment of the wheel award decal. If you change
the direction of the wheel's rotation, make sure to turn the wheel at least ONE FULL
REVOLUTION to make sure that the game software can re-track where the pointer is pointing to.
Possible Error Messages from Wheel Test:
MOTOR WIRES REVERSED:
The software has determined that the wires to the wheel motor
or the wires that transmit the drive signal to the Motor board
have been connected incorrectly. Reverse the orientation of the
wheel motors power wires and try this test again.
TRACKING FAILURE: The software cannot read the Wheel Inner Spin and Wheel Outer Spin
optos. Check the 12-volt power supply to the Wheel Opto board, and
check the individual switches using the T.1 Switch Test.
WARNING MOTOR DISABLED: The wheel may not be operating in game play because the
Motor Disabled (A2.08) adjustment has been set to YES.
T.18 EMPTY BALLS TEST
This test kicks out all balls loaded in troughs, lockups, poppers, and kick-outs until no balls
remain in those locations.
Note:
As the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order
to
allow further balls
to
be kicked out.
1-19
