GAME CONTROL LOCATIONS
NO
GOOD GOFERS features
a
new coin door display. When the coin door is open (in Attract
mode and game play), the display shows that the high-power has been disabled. It also shows the
Test Report (if there is anything
to
report), and some game specific information. Use the flipper
buttons
to
page through this information.
Cabinet Switches
The On-Off Switch is on the bottom of the cabinet near the right front leg.
The Start Button is a push-button to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Buttons
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses problems,
using only four push-button switches mounted on the inside of the coin door. The coin door buttons have
two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits button puts credits on the games that are not included in any of the game audits.
The Volume Up (+) button raises the sound level of the game. Press and hold the button until the
desired level is reached.
The Volume Down (-) button lowers the sound level of the game. Press and hold the button until the
desired level is reached. See Adjustment A.1
28
to turn sound off completely.
The Begin Test button starts the Menu System operation and changes the coin door buttons from
Normal Function to Test Function.
Test Function
The Escape button allows you to get out of a menu selection or return to the Attract mode.
The
.!.lQJ.+)
button allows you to cycle forward through the menu selections or adjustment choices.
The Down (-) button allows you to cycle backward through the menu selections or adjustment
choices.
The *Enter button allows you to get into a menu selection or lock in an adjustment choice.
COII\
DOOR BUTTONS
FRONT MOLDING
D-
1
2615
YELLOW START BUION
28-9663-16
LEVER GU:DE ASSEMBLY
A-16773-1
YELLOW
FliPPER
surros
ASSEMBLY
A-16883-6
BALL SHOOER ASSEM8L Y
8-12445-1
"To
reset High Score, hold down the Begin Test/Enter switch for five seconds while in the Attract
mode.
1-6
