Individual Playfield Opto Switch Wiring Diagram
This diagram shows the wiring for individual playfield opto switches only. See the next page for the wiring diagram
for the ball trough opto switches.
The individual playfield opto switches are:
Switch 38 Jet Popper
Switch 41 Left Gofer Down
Switch 42 Right Gofer Down
Switch 44 Putt Out Popper
Switch 45 Right Popper Jam
Switch 46 Right Popper
Each of these switches uses a green LED board
(pIn
A-16908), and a blue Photo Transistor board (pIn A-
16909).
OPTO SWITCH OPERTION:
The ball rolls between the LED board and the Photo Transistor board and breaks the beam. The broken beam
'makes' the switch.
o
er::
::1«
0..0
um
Cr:Cr::o
WWer::
52::«
oer::o
0..0 OJ
'"
..,
..
..,
:;
N
..,
3-20
