I. INSTALLATION
Assemble the game as follows:
Bolt legs to cabinet. Bolt back box to cabinet. Use flat
washers under bolt heads. Gently feed cable connectors and
ground braid through cable port in back box. Screw ground
braid to braid in back box. Carefully and fully insert
connectors on printed circuit assemblies.
On all games there are certain items that should be checked
after shipment. These are visual inspections which may avoid
time consuming service work later. Minor troubles caused by
abusive handling in shipment are unavoidable. Cable connec-
tors may be loosened, switches (especially tilt switches) may
go out of adjustment. Plumb bob tilt switch should always be
adjusted after game is set on location and leg levelers are
adjusted.
Visual inspections before plugging in line cord:
1. Check that all cable connectors are completely seated
on printed circuit assemblies.
2. Check that cables are clear of all moving parts.
3. Check for any wires that may have become disconnected.
4. Check switches for loose solder or other foreign
material that may have come loose in shipment and
could cause shorting of contacts.
5. Check wires on coils for proper soldering. Cold
solder connections may not show up in factory
inspection, but vibration in shipment may break
contact.
6. Check
that fuses are firmly seated and making good
contact.
7. Check the transformer for any foreign material
shorting across wiring lugs.
8. Check wiring of transformer to correspond to loca-
tion voltage. See Figure 1.
Check adjustment of the three (normally open) tilt switches:
1. Panel tilt on bottom of playfield panel.
2. Plumb bob tilt on left side of cabinet near front door.
3. Ball tilt above plumb bob tilt. Insert the smaller
ball (15/16" dia.) into the ball tilt assembly, and
adjust the bracket so the ball will roll free to
contact the switch blade, if front of cabinet is
raised.
-1-
