V.
GAME ADJUSTMENTS
A. Playfield Panel Post Adjustments:
Posts that control left and right outlane opening on panel can be
moved
to make access to
outlanes easier or harder for ball to enter. 5ee Figure II.
'
Easier entry will decrease playing time and scoring (conservative).
Harder entry will increase playing time and scoring (liberal).
B. Back Box Game Adjustments:
'.
.ii;'
Each game has thirty-two switches located on A4, the MPU module, located in the backbox
that allow play to be customized to the location. See Figure III. Credits per coin, maxirriurn
credits, credit display, balls per game, match feature, high game feature, special award and
melody are selectable by means of the switches. The switches are contained in four-sixteen
lead packages numbered 51-8, 59-16, 517-24 and 525·32 for easy identification. The "ON"
toggle position is marked on the assembly. Turn off power before making adjustments.
Credits/Coin.Adjustments:
The credits per coin are selectable by means of 517-520 for coin chute #2. The switch settings
and resultant credits! coin are as follows:
520 519 518 517
Credits /Coin
OFF OFF OFF OFF
Same as Coin Chute #1 Settlngs
OFF OFF OFF ON
1/1 Coin
OFF OFF ON OFF
2/1 Coin
}~ : '
OFF OFF ON ON
3/1
Coin
OFF ON OFF OFF
4/1 Coin
OFF ON OFF ON
511
Coin
OFF ON ON OFF 6/1 Coin
OFF ON ON ON
7/1
Coin
ON· OFF OFF OFF
8/1
Coin
ON OFF OFF ON
9/1
Coin
ON OFF ON OFF
1011
Coin
ON OFF ON ON
1111
Coin
ON ON OFF OFF
12/1 Coin
ON ON OFF ON
13/1 Coin
ON.
ON ON OFF
1411
Coin
ON ON ON ON
15/1 Coin
The credits given per coin are selectable by means of switches 1-5 incl., for coin chute #1 and
switches 9-13 incl., for coin chute #3. Thirty-one different credit ratios are available for each
coin chute. The switch settings and resultant credits/coin are listed b.elow.
CREDIT5/COIN AOJUSTMENTS
COIN CHUTE
SWITCHES
CREDITS/COIN
# 1 (HINGE SIDE)
5
4
3
2
1
OR #3
13 12 11 10
9
OFF OFF OFF OFF OFF 3/2 COINS"
OFF OFF QFF OFF ON 3/2 COINS"
OFF OFF OFF ON OFF llCOIN
OFF OFF OFF ON ON
1/2
COINS'
OFF OFF ON OFF OFF 2/COIN
OFF OFF ON OFF ON
2/2
COINS'
.,~--
OFF OFF ON ON OFF 3/COIN
OFF OFF ON ON ON
3/2
COINS'
OFF ON OFF OFF OFF 4/COIN'
OFF ON OFF OFF ON
4/2
COINS'
OFF ON OFF ON OFF 5/COIN
OFF ON OFF ON ON
5/2
COINS'
OFF ON ON OFF OFF 6iCOIN
OFF ON 'ON OFF ON
6/2
COINS'
OFF ON ON ON OFF 7/COIN
OFF ON ON ON ON
7/2
COINS'
ON OFF OFF OFF OFF 8/COIN
ON OFF OFF OFF ON
8/2
COINS'
ON OFF OFF ON OFF 9/COIN
ON OFF OFF ON ON
9/2
COINS'
ON OFF ON OFF OFF 10/COIN
'No Credits until second coin is dropped
ON OFF ON OFF ON
10/2
COINS'
"One Credit for first coin, Two Credits tor second
ON OFF ON ON OFF l11COIN
coin provided that no scoring occured between
ON OFF ON ON ON
11/2
COINS'
tst and zno coin drops. If scoring occureo.
ON ON OFf
OFF OFF 12/COIN
second coin gives one credit
ON ON OFF OFF ON
12/2
COINS'
ON ON OFF ON OFF 13/COIN
ON ON OFF ON ON
13/2
COINS'
ON ON ON opp OFF 14/COIN
ON ON ON OPe ON
14/2
COINS'
ON ON ON ON OFF
151
COIN
ON ON ON ON ON
15/2
COINS'
5
