A4:
MPUMODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM DESIGNATION
PART
#
DESC.RIPTION
1
A4 (see note 1)
AS-2962-18
MPU Module Complete.
Mystic
2
A4 (see note 2)
AS-2518-35
MPU Module less Program
Memory, U1-6 incl.
3-32
See Schematic
Resistors, Seeschematic for value
33
C14, C15
E-00586-0067 Capacitor, 470 PFD, 1kv
34
C18
E-00586-0088 Capacitor, .05 MFD, 16V
35
C16
E-00586-0081 Capacitor,.l
MFD, 100V
36
C4,C5
E-00586-0073 Capacitor, 4.5 MFD, 25V
37
C3, C6-C13, C17, C81
E-00586-0085 Capacitor, .01 MFD, 25V
38
C79, C41-C67
E-00586-0083 Capacitor, 470 PFD, 50V
39
C19-C31, C78, C33-C40 E-00586-0082 Capacitor, 390 PFD, 50V
40
ci,
C2, C68-C77
E-00586-0084 Capacitor, 820 PFD, 50V
41
C32
E-00586-0077 Capacitor, 3000 PF, 1kv
43
Q5
E-00585-0023 Transistor PNP (MPS-3702)
44
Q1,Q2
E-00585-0031 Transistor (2N3904)
47
CR44
E-00587-0006 Diode (lN4004)
48
CR1-CR7, CRll-CR43,
E-00587-0014
Diode (lN4148)
CR45-CR49
49
CR8
E-00679
LED (Green)
50
VRl
E-00598-0008
Diode Zener (8.2V, IN9598)
52
L1,L2
E-00604-0003
Inductor, 22 Micro Hy.
53
U12
E-00620-0004 Timer (555)
54
U19
E-00620-0005 Quad 21nput (4011)
55
U9
E-00620-0028 MPU I.C. (6800)
56
Ul0, U11
E-00620-0029 PIA I.C. (6820)
57
U7
E-00620-0Q30 RAM I.C. (6810)
59
U20
E-00620-0Q32 HEX Buffer I.C. (145028)
60
U14,U18
E-00620-Q033 HEX Inverter (4049B)
61
U15
E-00620-0034 Quad Memory Drive (MC3459L)
62
U16
E-00620-0035
Dual Monostable (9602)
64
U17
E-0062Q-OQ41 Quad 21nputs (74LOON)
65
U8
E-00620-0Q42 RAM (C MOS, P51Q1L-3)
68
BTl, BT2, BT3
E-00628,QOQ3 Battery
70
S33
E-0065fj.OQ01 Push Button Switch
71
S1-S8, S9-S16, S17-S24,
E-006Ti'
DIP Switch
S25-S32
73
E-00712
24 Pin Socket
74
E-00712-0001 40 Pin Socket
75
E-00712-00Q3 22 Pin Socket
77
J2
E-00715
15 Pin Wafer Connector
78
J1
E-00716-0004 28 Pin Wafer Connector
79
J3,J5
E-00715-0017
16 Pin Wafer Connector
80
J4
E-00715·0Q18 19 Pin Wafer Connector
81
J5
E-00715-0Q24 17 Pin Wafer Connector
NOTE1:
Whenordering,fill in dashnumber.Forexample,AS-2962-0:LOSTWORLD,AS,2962-2:SIX MILLIONDOLLAR
MAN, AS-2962-3: PLAYBOY,AS-2962-4: VOLTAN,AS-296,H'i: SUPERSONIC,AS-2962-6: STARTREK, AS-
2962-7: KISS, AS-2962-8: PARAGON,AS-2962-9:GROLJNDSHAKER, AS-2!).62-10HARLEMGLOBETROT-
TERS,AS-2962-12:DOLLYPARTON,AS-2962-13:SILVEFIBALLMANIA,AS-2962-18:MYSTIC
NOTE
2:'
Order replacementmemorychipsU1-U6,speCifyinggame, socketand part numberstampedon Chip.
22
