Coin Lockout
.
Flipper (2)
.
.
XL PARTS LIST
#1192 MYSTIC
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-125
Bulbs, #44
. .. E-125-22
Fuse,1 Amp. 3 AG Slow Blow (Playfield Solenoid Protection)
E-133-44
ASSEMBLY COILS
.
FO-36- 7000
.
AQ-25-500/
34-4500
Knocker,
,
,
AR-26-1200
Outhole Kicker
AN-26-1200
Thumper-Bumper (3)
AO-26-1200
Sling-Shot (2) . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
. . AN-26-1200
Drop Target (3)
NO-26-1900
Saucer
AO-27 -1300
PLAYFIELD PARTS
MODULES
Lamp Driver A5
AS-2518-23
Display Driver A 1 (5 used)
AS-2518-21
Solenoid DriverlVoltage Regulator A3 . . . . . . . . . . . . . . .
. .. AS-2S18-22
MPU A4 . . . . . . . .
.
AS-2962-18
Transformer & Rectifier A2 .............................•............
AS-2877-1
Rectifier Board (Part of A2) ; . . . . . . . . . . . . . . ..
. . . . . . . . . .. .
AS-2518~18
Sound
,........................
. . . . . . . . . .
.
AS-3022-7
See Figure II
REPAIRS PROCEDURES/AIDS
Module
&
Component Replacement
FO.560-1
AIO (Assistance in Diagnostics)
Kit, used with FO.560-1
KIT #485-1
MOPVLECOMPONENTS
SEg MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module repair.)
Kit #490--'-For Rectifier Board (Part of A2)
Kit #ti03-For
MPU Board A4 (Less Memory U1-U6)
Kit #492-For
Solenoid DriverlVoltage Regulator A3
Kit #493-For
Display Driver A 1
Kit #494-For
Lamp Driver A5
Kit #559-For
Sound A8
