MENU SYSTEM OPERATION
The Main Menu allows you to choose from several options, which in turn lead to other menus to choose
from. To access the Main Menu open the coin door, press the Begin Test button, then the Enter button.
Press the Up and Down buttons to scroll through the Main Menu. To access a menu, (Bookkeeping,
Printouts, etc.), from the Main Menu, press the Enter button. To return to the Main Menu (from
Bookkeeping, Printouts, etc.) press the Escape button. Press the Start button for HELP.
B BOOKKEEPING MENU
MAIN MENU
B.1 Main Audits
B.2 Eaming Audits
B.3 Standard Audits
B.4 Feature Audits
B.S Histograms
B.6 Time-Stamps
P. PRINTOUTS MENU
P.1 Eamings Data
P.2 Main Audits
P.3 Standard Audits
P.4 Feature Audits
P.S Score Histograms
P.6 Time Histograms
P.7 Time-Stamps
P.S All Data
T. TEST MENU
T.1 Switch Edges Test
T.2 Switch Levels Test
T.3 Single Switches Test
T.4 Solenoid Test
T.S Flasher Test
T.6 General Illumination Test
T.7 Sound and Music Test
T.S Single Lamp Test
T.9 All Lamps Test
T.10 Lamp and Flasher Test
T .11 Display Test
T.12 Flipper Coil Test
T.13 Ordered Lamps Test
T.14 Lam_p Row-Col.
T.1S DIP Switch Test
T .16 Loop/Gate Test
T.17 UplDown Bank Test
T.1S Frankenstein Table Test
T .19 Dracula Test
T.20 Empty Balls Test
U. UTIUTIES MENU
U.1 Clear Audits
U.2 Clear Coins
U.3 Reset H.S.T.D.
U.4 Set Time and Date
U.S Custom Message
U.6 Set Game
1.0.
U.7 Factory Adjustments
U.S Factory Resets
U.9 Presets
U.10 Clear Credits
U.11 Auto Bum-in
U.12 Reset Phantom Flip Data
A. ADJUSTMENT MENU
A.1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.D. Adjustments
A.S Printer Adjustments
1-9
Press Escape
To move out of a menu selection.
Press Enter
To get into a menu selection.
Press Up
Increases sequence; Example A.1, A.2, A.3, A.4.
Press Down
Decreases sequence; Example A.4, A.3, A.2, A.1.
Use Up or Down to cycle through the selections in a
menu.
Use Escape and Enter to move into and out of the
selected menu.
