12. Install full playfield Mylar, if desired.
Note: The MONSTER BASH playfield is coated with
a
special hardcoat surface and does not require
a
protective Mylar. However, mylars can be purchased through your local Williams Distributor.
13. Clean and reinstall the playfield cover glass. Replace and lock the front molding.
14. To attach the line cord, remove the four Phillips-head screws that mount to line cord cover plate to the
rear cabinet. Match the prongs on the plug with the holes in the receptacle, and push the line cord
securely into place. Make sure the cord is aligned with the indentation on the cover plate (indentation
should point toward bottom of the cabinet). Remount line cord cover plate. If desired, four tamper
resistant screws have been provided, in the unique parts bag, to remount cover plate.
(Part of cabinet shown
for reference only)
~
Receptacle
"
r
lom"'-~;",",
'0".
line Cord & Plug
15. Move the game into the desired location. Adjust the leg levelers so that the playfield pitch is the
recommended
6-1/2
degrees. This places the game in a FIXED position.
16. If a padlock is desired, install the security bar as shown below.
Ho.sp HingE' Br-c cke t
01-14085
Ho .sp St<lp le Br<lcket
01-14086
17. IMPORTANT: Fill out and return the registration card.
1-5
