PINBALL
GAME ASSEMBLY INSTRUCTIONS
..MONSTER BASH IS A FOUR BALL GAME-
Domestic 120V
@
60Hz
Foreign 230V
@
50Hz
Japan 100V
@
50HZ
32°F to 100° F, (O°C to 38°C)
Not to exceed 95% relative.
Power:
Temp:
Humidity:
Dimensions:
Width: 29" approx.
Depth: 52" approx.
Height: 75" approx.
Weight:
325 lb. approx. (crated)
1. Remove all cartons, parts, and other items from the shipping container and set them aside.
2. The leg levelers and leg bolts are among the parts in the cash box. Install the leg levelers on the
front and rear legs (View 1). Place the cabinet on a support and attach the rear legs using leg bolts
(View 2).
3. Attach front legs using leg bolts (View 2).
/7~
~~
j@
:~
:
\.
1
\
::.
Coin Door
"
'.
'.
H
11
ii
FRONT
VIEW 1
Detailed View-Leg Leveler
~
\\\\1\
"
.'
.,
n
1\
REAR
VIEW 2
1-2
000
c
0
0
