Power
Driver
Board
Continued •••
J109-1 BlU·BRN Solenoid #25 drive to playfield flasher
J119-1 RED·GRN +50V to lower right flipper coil.
J109-2 BLU-RED Solenoid #26 drive to playfield flasher
J119-2 RED·GRN loop from J 119-1.
J109-3 BlU·ORG Solenoid #27 drive to playfield flasher
J119-3 KEY
J109-4 BlU-YEl
Solenoid #28 drive to playfield flasher
J119-4 RED·BlU +50V to lower left flipper coil.
J109-5 N/C
J119-5 RED·BlU loop from J 119-4.
J109-6 N/C
J119-6 N/C
J109-7 KEY
J119-7 N/C
J109-8 N/C
J119-8 N/C
J109-9 N/C
J119-9 N/C
J11Q-1 BRN-WHT Solenoid #37 drive to DC Motor Control
J120-1 N/C
J110-2 KEY
J120-2 N/C
J110-3 ORG·WHT Solenoid #38 drive to DC Motor Control
J120-3 N/C
J110-4 YEl-WHT NOT USED
J120-4 N/C
J110-5 BlU-WHT NOT USED
J120-5 N/C
J120-6 N/C
J111-1 BlK-BRN Solenoid #17 drive to playfield flasher
J120-7 ORG-BlU Solenoid #32 hold drive to low left flipper
J111-2 BlK-RED Solenoid #18 drive to playfield flasher
J120-8 N/C
J111-3 BlK-ORG Solenoid #19 drive to playfield flasher
J120-9 YEl·BLU Solenoid #31 power drive to low left flipper
J111-4 BlK-YEl
Solenoid #20 drive to playfield flasher
J120-10 KEY
J111-5 BlU-GRN Solenoid #21 drive to playfield flasher
J120-11 ORG·GRN Solenoid #30 hold drive to low right flipper
J111-6 BLU·BlK Solenoid #22 drive to playfield flasher
J120-12 N/C
J111-7 BlU·VIO Solenoid #23 drive to playfield flasher
J120-13 YEl·GRN Solenoid #29 power drive to low right flipper
J111-8 BlU-GRY Solenoid #24 drive to playfield flasher
J111-9 KEY
J121
NOT USED
J111-10 N/C
J111-11 N/C
J122-1 KEY
J111-12 N/C
J122-2 N/C
J111-13 N/C
J122-3 YEl·GRY lamp column #8 to cabinet
J112-1 BlK·BRN Solenoid #17 drive to insert flasher
J123-1 YEl·BRN Lamp column #1 to playfield
J112-2 BlK-RED Solenoid #18drive to insert flasher
J123-2 YEl-RED lamp column #2 to playfield
J112-3 BlK-ORG Solenoid #19 drive to insert flasher
J123-3 YEl·ORG lamp column #3 to playfield
J112-4 KEY
J123-4 YEl·BLK lamp column #4 to playfield
J112-5 BlK-YEl
Solenoid #20 driver to insert flasher
J123-5 YEl·GRN lamp column #5 to playfield
J112-6 N/C
J123-6 YEl·BlU Lamp column #6 to playfield
J112-7 BlU·BlK Solenoid #22 driver to insert flasher
J123-7 YEl·VIO Lamp column #7 to playfield
J112-8 N/C
J123-8 KEY
J112-9 N/C
J123-3 YEl·GRY lamp column #8 to playfield
J113-1 BRN·BlK Solenoid #9 drive to playfield coil
J124-1 N/C
J113-2 KEY
J124-2 N/C
J113-3 BRN·RED Solenoid #10 drive to playfield coil
J124-3 KEY
J113-4 BRN·ORG Solenoid #11 drive to playfield coil
J124-4 N/C
J113-5 BRN·YEl
Solenoid #12 drive to playfield coil
J124-5 N/C
J113-6 BRN·GRN Solenoid #13 drive to playfield coil
J124-6 N/C
J113-7 BRN·BlU Solenoid #14 drive to playfield coil
J124-7 RED·BlU Lamp row #6 to coin door board J3-9
J113-8 BRN·VIO Solenoid #15 drive to playfield coil
J124-8 RED·VIO lamp row #7 to coin door board J3-1 0
J113-9 BRN·GRY Solenoid #16 drive to playfield coil
J124-9 RED·GRY lamp row #8 to coin door board J3-11
J114
NOT USED
J125-1 RED-BRN Lamp row #1 to playfield.
J125-2 RED-BlK Lamp row #2 to playfield.
J115
NOT USED
J125-3 KEY
J125-4 RED·ORG lamp row #3 to playfield
J116-1 VIO·BRN Solenoid #1 drive to playfield coil
J125-5 RED·YEl
Lamp row #4 to playfield
J116-2 VIO·RED Solenoid #2 drive to playfield coil
J125-6 RED·GRN Lamp row #5 to playfield
J116-3 KEY
J125-7 RED·BlU lamp row #6 to playfield
J116-4 VIO·ORG Solenoid #3 drive to playfield coil
J125-8 RED·VIO lamp row #7 to playfield
J116-5 N/C
J125-9 RED·GRY Lamp row #8 to playfield
J116-6 VIO·GRN Solenoid #5 drive to playfield coil
J116-7 VIO·BlU Solenoid #6 drive to playfield coil
J126
NOT USED
J116-8 VIO-BlK SolenOid #7 drive to playfield coil
J116-9 VIO·GRY Solenoid #8 drive to playfield coil
J127-1 WHT·GRN 9.8VAC from transformer secondary.
J127-2 WHT-GRN 9.8VAC loop from J127-1.
J117
NOT USED
J127-3 WHT-GRN 9.8VAC from transformer secondary.
J127-4 KEY
J118
NOT USED
J127-5 WHT·GRN 9.8VAC loop from J127-3.
