HIGH POWER SOLENOID CIRCUIT
1-~------------------+50V---1
I Drive lN4004 I
I I
I
I
I
I
I
: POWER DRIVER BOARD
I
I
I
I
I
I
I
I 6f-----.
: ~o
I Power - -=- I
L ~
Red-Brown
Violet-XXX
+
I
I
I
I
I
!
I
!
J133 I
COIL
019
lOami
021 100V
The microprocessor toggles the output of the 74LS374. When point "An is low, point "B", the collector of
the 2N5401 transistor, is high. A high at point "B" causes point "e", the collector of the TIP102 transistor
and point "D", the emitter of the TIP3Se transistor, to drop low. When paint "0" is low, the coil is
grounded through the transistor and turns on. The coil shuts off when point "A" toggles high.
LOW POWER SOLENOID CIRCUIT r-~----------------------l
I Drive vee I
-sov
I I
I I
I X
I
I
I
I
I
I
I
I
I
I
I
I 61-------,
I 5 ~D I
I I
Power -e-' -=- L J
COIL
Brown-XXX
POWER DRIVER BOARD
Fl0B
100mfl
loci..iL
Red-Block +
The microprocessor toggles the output of the 74LS374. When point "An is low, point "B", the collector of
the 2N5401 transistor, is high. A high at point "B" turns on the TIP102 transistor and causes point "C" to
drop low. When point "C" is low the coil is grounded through the transistor and turns on. The coil shuts
off when point "An toggles high.
