A..22275 Up/Down Target Assembly
Item Part Number
Description
1
A-22276
Slide Bracket Assembly
a) 04-11218
Slide Bracket
b) 07-6688-16N
Rivet:
1/8
x
1/8"
c) 01-14833
UplDown Flap
2
04-11167
Cam
3
04-11166
Main Bracket
4
03-9859
Slide Roller
5
03-9860.
Roller
6
01-14835
Fish Paper
7
A-22404
Motor & Gearbox Assembly
a) 14-8015
Motor
b) 03-9222
Pinion Gear
c) 03-9219
Gear Cluster
d) 03-9219-2
Gear Cluster
e) 20-10131-07Y Metric Screw: M2.6 x 8"
f) 02-5450
Standoff
g) 02-5444
Shaft
h) 02-5443
Drive Shaft
j) 20-8712-12
E-Ring
1/8"
k) 4700-00004-00
Flat Washer:
9/64
x
3/8
x 21 gao
m) 4008-01168-04
Mach. Screw: 8-32 x
%
Hex
Headw/SEMS
n) 04-11168
Motor Mounting Bracket
p) 04-11183
Faceplate
q) 03-9873
Spacer
8
A-22414-1
Standup Target Assembly, Blue
9
03-9835
Pivot Spacer (2)
10
01-8240
Plate Nut #2-56 (2)
11
5647-12639-36
Mini Micro Switch (2)
12
20-8712-18
E-Ring,
3/16"
Shaft (4)
13
4404-01119-00
Nut 4-40 ESNA (4)
14
4002-01105-10
Mach. Screw: 2-56 x
5/8"
15
4408-01119-01
Nut 8-32 ESNA
16
4700-00003-00
Flat Washer:
1/8
x
9/32
x 21 gao
17
03-9454
Cable Tie 4" Long
18
01-8657
Bracket Stop
19
23-6534-9
Rubber Protector
3/8"
20
SW-1A-217-4
Standup Target Assembly (2)
21
01-3670
Sw. Curved Plate (3)
22
4700-00123-00
Flat Washer:
7/32
x
7/16
x 18ga.
23
4008-01083-04
Set Screw 8-32
24
H-1860D-1
Cable, Gen Motor 2-pin 8"
25
H-22444
Cable, Up Down Bank Target
26
5070-09054-00
Diode 1N4004 1.0A.
27
H-22445
Cable, Left Right Bank Target
28
4004-01005-16
Mach. Screw, 4-40 xi" (2)
2-32
