SELF-
TEST
#
SOLENOID IDENTIFICATION
10 BOTTOM RIGHT THUMPER BUMPER
11 LEFT SLINGSHOT
12 RIGHT SLINGSHOT
13 TOP SAUCER
14 LEFT DROP TARGET
15 RIGHT DROP TARGET
16 COIN LOCKOUT DOOR
17 K1 RELAyl(FLIPPER ENABLE)
GAME #11 04-E MATA-HARI
SOLENOID IDENTIFICATION TABLE
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
)
SELF-
TEST # SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
02 KNOCKER
03 CHIME 10
04 CHIME 100
05 CHIME 1000
06 CHIME 10,000
07 BOTTOM LEFT THUMPER BUMPER
08 TOP LEFT THUMPER BUMPER
09 TOP RIGHT THUMPER BUMPER
SELF-
TEST
#
SWITCH DESCRIPTION
06 CREDIT BUTTON
07 TILT (3)
08 OUTHOLE
09 COIN III (RIGHT)
10 COIN I (LEFT)
11 COIN II (MIDDLE, IF USED)
16 SLAM (2)
17 RT.DROP TARGET D (BOTTOM)
18 RT.DROPTARGET C
19 RT.DROP TARGET B
20 RT.DROP TARGET A (TOP)
21 LEFT DROP TARGET D (BOTTOM)
22 LEFT DROP TARGET C
23 LEFT DROP TARGET B
24 LEFT DROP TARGET A (TOP)
25 RIGHT FLIPPER FEEDER LANE
SELF-
TEST
#
SWITCH DESCRIPTION
26 LEFT FLIPPER FEEDER LANE
27 10 PT.OROP TARGET REBOUND (2)
28 RIGHT 'B' LANE
29 LEFT'~ LANE
30 TOP 'B' LANE
31 TOP'~ LANE
32 TOP SAUCER
33 RIGHT OUTLANE
34 LEFT OUTLANE
35 RIGHT SLINGSHOT
36 LEFT SLINGSHOT
37 BOTTOM RIGHT THUMPER BUMPER
38 BOTTOM LEFT THUMPER BUMPER
39 TOP RIGHT THUMPER BUMPER
40 TOP LEFT THUMPER BUMPER
17
