A3: SOLENOID DRIVER/VOLTAGE REGULATOR MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
A3
AS-2518-22
Solenoid Driver/Voltage
Regulator Module, Complete
3-14
Resistors
Resistor, See Schematic for'
value.
15
RT1
E-00599-0014
Pot. (Linear) 25K
17
C25,29
E-00586-0014
Capacitor,,1 MFD,20V
18
C26
E-00586-0059
Capacitor, 160 MFD, 350V
19
C24
E-00586-0063
Capacitor. 2 MFD
@
25V
20
C23
E-00586-0062
Capacitor, 11700 MFD, 20V
21
C1-C8, C11-C21
E-00586-0064
Capacitor, .002 MFD, 1kv
22
C22, C27, C28
E-00586-0065
Capacitor, .01 MFD, 500V
24
K1
E-00146-0795
Relay, Printed Circuit.
25
01-019
E-00585-0034
Transistor, SE9302
26
022,023
E-00585-0041
Transistor, 2N3440
27
021
E-00585-0042
Transistor, 2N3584
28
020
E-00710
+
5V Regulator, LAS 1405 or.
78H05KC or LM323K
30
CR1-CR21
E-00587-0015
Diode (IN4004)
31
VR1
E-00598-0010
Diode, Zener
140\1,
IN5275A
33
U1, U3, U4
E-00681
I.C. Transistor Array, CA3081
34
U2
E-00620-0039
I.C. Binary to 1/16 Decoder,
74L154
36
E-00592-0002*
Relay Socket
37
M-1839*
Relay Holder
39
E-00682
Heat Sink, T05
40
E-00682-0001
Heat Sink, T066
41
E-00682-0002
Heat Sink, T03 Case
42
E-00715-0013
15 Pin Wafer Connector
43
E-00715-0016
12 Pin Wafer Connector
44
E-00715-0020
25 Pin Wafer 'Connector
45
E-00715-0021
9 Pin Wafer Connector
55
M-1837
Shield-Plexiglass
59
E-00148-0021
Fuse Clips
60
F1
E-00133-0029
Fuse 8 AG-3/16 Amp.
. ,
.. ,.
.:.,
*USED WITH ITEM24, E-0014S-0791,PLUG IN RELAYONLY
