AS-2S18-21 DISPLAY DRIVER MODULE
A1:rOISPLAY DRIVER MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM QTY.
DESIGNATION
PART
#
DESCRIPTION
1
1
P-2948-296
P.C. Board, M-64S-392
3
7
R1,R3,RS,R7,R9,R11,R34
E-10S-226
Resistor, 1OOKQ
4
13
R14,R16,R18,R20,R22,
E-10S-227
Resistor, 300K Q
R24,R26,R3S,R36,R37,
R38,R39,R40
S 6
R43, R44, R4S, R46, R47,
E-10S-228
Resistor, 9.1K Q
R48
6
7
R13,R1S,R17,R19,R21,
E-10S-229
Resistor, 1.SK Q
R23, R2S
7
7
R27, R28, R29, R30, R31,
E-10S-230
Resistor, 1K Q
R32,R33
8
1
R41
E-10S-231
Resistor, 39K Q
9
1
R42
E-10S-271
Resistor, 240K Q
10
11
2
C1,C2
E-S86-6S
Capacitor, .01 MFD
13
6
07,08,09,010,011,012
E-S8S-32
Transistor (2NS401)
14 13
01, 02, 03, 04,
OS,
06,
E-S8S-33
Transistor (MPS-A42)
013,014,
01S,
016, 017,
018,019
16
VR1
E-S98-7
Zener Diode, 110V
17
U1
E-620-38
I.C. Decoder
18
19
2
J1
E-71S-11
10 Pin Wafer Pin Connector
21
1
DS1
E-680
Digital Display Panel
22
2
M-1836
Hi-Lo Screw,
W/H
23
1
P-2399
Display Mounting (Top)
24
1
P-2399-1
Display Mounting (Bottom)
26
6
R2,R4,R6,R8,R10,R12
E-105--287
Resistor, 2.2K
n
27
6
R49, R50, RS1, RS2, RS3,
E-10S-242
Resistor, 20K
n
•
RS4
28 As
Wire Jumper
Req'd
NOTE:
INTERCHANGEABLE WITH AS-2518-15
