26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
LEFT FLIPPER FEEDER LANE
10 PT. PROP TARGET REBOUND (2)
RIGHT 'B' LANE
LEFT 'A' LANE
TOP 'B' LANE
TOP '/\ LANE
TOP SAUCER
RIGHT OUTLANE
LEFT OUTLANE
RIGHT SLINGSHOT
LEFT SLINGSHOT
BOTTOM RIGHT THUMPER BUMPER
BOTTOM LEFT THUMPER BUMPER
TOP RIGHT THUMPER BUMPER
TOP LEFT THUMPER BUMPER
GAME #11 04-E MATA-HARI
SOLE~OID IDENTIFICATION TABLE
SELF-
TEST
#
SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
02 KNOCKER
03 CHIME 10
04 CHIME 100
05 CHIME 1000
06 CHIME 10,000
07 BOTTOM LEFT THUMPER BUMPER
08 TOP LEFT THUMPER BUMPER
09 TOP RIGHT THUMPER BUMPER
SELF-
TEST
#
SOLENOID IDENTIFICATION
10 BOTTOM RIGHT THUMPER BUMPER
11 LEFT SLINGSHOT
12 RIGHT SLINGSHOT
13 TOP SAUCER
14 LEFT DROP TARGET
15 RIGHT DROP TARGET
16 COIN LOCKOUT DOOR
17 K1 RELAyl(FLIPPER ENABLE)
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
)
SELF-
TEST
#
SWITCH DESCRIPTION
06 CREDIT BUTTON
07 TILT (3)
08 OUTHOLE
09 COIN III (RIGHT)
10 COIN I (LEFT)
11 COIN II (MIDDLE, IF USED)
16 SLAM (2)
17 RT. DROP TARGET
0
(BOTTOM)
18 RT. DROP TARGET C
19 AT. DROP TARGET B
20 RT. DROP TARGET A (TOP)
21 LEFT DROP TARGET
0
(BOTTOM)
22 LEFT DROP TARGET C
23 LEFT DROP TARGET B
24 LEFT DROP TARGET A (TOP)
25 RIGHT FLIPPER FEEDER LANE
SELF-
TEST
#
SWITCH DESCRIPTION
17
