XI. PARTS LIST
#1119-E LOST WORLD
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-125
Bulbs, #44
E-125-22
ASSEMBLY COILS
Coin Lockout
FO-36-7000
Flipper Left
&
Right (2)
AQ-25-500/
. 34-4500
Knocker
AR-26-1200
Outhole Kicker
,
AN-26-1200
Saucer (2)
AO-27-1300
Thumper-Bumper (3)
AN-26-1200
Sling-Shot(2)
AN-26-1200
PLAYFIELD PARTS
See Figure II
MODULES
Lamp Driver A5
AS-2518-23
Display Driver A1 (5 Used)
AS-2518-21
Solenoid Driver/Voltage Regulator A3
AS-2518-22
.MPU A4
AS-2962
Transformer
&
Rectifier A2
AS-2877-1
Rectifier Board (Part of A2)
AS-2511-18
Sound
AS-2888-1
REPAIRS PROCEDURES/AIDS
Module
&
Component Replacement
F.O. 560-1
AID (Assistance in Diagnostics)
Kit, used with F.O. 560-1
KIT#485-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module repair.)
Kit #490-Rectifier
Board (Part of A2)
Kit #503-MPU Board A4 (Less Memory U1-U6)
Kit #492-Solenoid Driver/Voltage Regulator A3
Kit #493-Display Driver A1
Kit #494-Lamp Driver A5
20
