NOTICE:
THIS GAME OPERATES ON 24 VOLTS.
WHEN ORDERING REPLACEMENT TRANSFORMERS,
MOTORS,
COILS
OR METERS ••••
MAKE SURE TO SPECIFY CORRECT PART
NUM8t;1(.
NUMBER
DESCRIPTION
LOCATION
MOTOIS
&
TRANSFORMERS
14 A-78B3
CONTROL MOTOR - 60 CYCLE
MECH.
PANEL
14 A-7884
CONTROL MOTOR - 50 CYCLE
MECH.
PANEL
15 A-6771
TRANSFORMER - 60 CYCLE
MECH.
PANEL
15 A-6782-1
TRANSFORMER - 50 CYCLE
MECH.
PANEL
B 6396
24 VOLT METER
MECH.
PANEL
SOLENClm COILS
A 22-550
COIN UNIT STEP UP
MECH.
PANEL
BONUS UNIT STEP UP
PIAYFIELD
BALL RELEASE COIL
PIAYFIELD .
PLAYER UNIT STEP UP
INSERT
A 23-600
BALL COUNT UNIT STEP UP
MECH.
PANEL
CREDIT UNIT STEP UP
INSERT
A2-23-750
KNOCKER
CABINET
A2-26-1300
TRIPLE CHIMES COILS ••• (3 req'd.)
CABINET
81-26-600
SCORE DRUM UNITS ...
(16 req'd.)
INSERT
BALL COUNT UNIT RESET
MECH.
PANEL
COIN UNIT RESET
MECH.
PANEL
CREDIT UNIT RESET
INSERT
PLAYER UNIT RESET
INSERT
BONUS UNIT RE~ET
PLAYFltLD
FL 20-300/
28-400
FLIPPERS ••• (2 req'd.)
PLAYFIELD
G 23-750
EJECT COIL
PLAYFIELD
G 23-750 D.C.
D.C.
JET BUMPER COILS ••• (2 req'd.)
PLAYFIELD
D. C. KICKER COILS ..,.
(2 req'd.)
PIAYFIELD
M 29-900
1 - 2 RESET RELAY
INSERT
3 - 4 RESET RELAY
INSERT
M 29-1000
GAME OVER RELAY TRIP
MECH.
PANEL
M 29-1100
10<;; RELAY
MECH.
PANEL
25¢ RELAY
MECH.
PANEL
10 POINT RELAY
INSERT
100 POINT RELAY
INSERT
1,000 POINT RELAY
INSERT
50 POINT RELAY
PLAYFIELD
ADVANCE RELAY
PLAYFIELD
EJECT UNIT RESET RELAY
PLAYFIELD
GATE BONUS CONTROL RELAY
PLAYFIELD
M 30-1300
GATE RELAY
PLAYFIELD
SPECIAL RELAY
PLAYFIELD
EXTRA SPECIAL RELAY
PLAYFIELD
COIN SET UP RELAY
MECH.
PAN:&L
M 30-1400
CHANGE RELAY
PLAYFIELD
MI-31-1S00
COIN LOCKOUT RELAY
FRONT DOOR
XM 27-675
TOTAL PLAY METER COIL
CABINET
XS 28-1000
ALTERNATOR UNIT
MECH.
PANEL
EJECT ADVANCE UNIT
PLAYFIELD
NUMBER MATCH UNIT
INSERT
Z 27-1000
COIN RELAY
MECH.
PANEL
RESET RELAY
MECH.
PANEL
PLAYER RESET RELAY
MECH.
PANEL
OUTHOLE RELAY
MECH.
PANEL
GAME OVER RELAY LATCH
MECH.
PANEL
BONUS RELAY
PLAYFIELD
EJECT RELAY
PLAYFIELD
"A" RELAY
PLAYFIELD
Z 28-11 50
"B" RELAY
PLAYFIELD
DOUBLE BONUS RELAY
PLAYFIELD
MECH.
PANEL
BALL INDEX RELAY
MECH.
PANEL
TILT RELAY
MECH.
PANEL
EXTRA BALL RELAY
LOCK RELAY
MECH.
PANEL
11
Z 29-1250
