XI. PARTS LIST
#1152-E KISS
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-131
Bulbs, #44
:
E-125-22
Fuse, 1 AMp, 3 AG, slow blow (Playfield solenoid protection)
E-133-44
ASSEMBLY COILS
Coin Lockout
FO-36-7000
Flipper Left & Right (2)
AQ-25-500/
34-4500
Knocker
AR-26-1200
Outhole Kicker
AN-26-1200
Gate
.'
GA-34-4000
Thumper-Bumper (4)
AN-26-1200
Sling-Shot (2)
AN-26-1200
Drop Target Reset
NO-26-1900
PLAYFIELD PARTS
See Figure II
MODULES
Lamp Driver A5
AS-2518-23
Display Driver A1 (5 Used)
AS-2518-21
Solenoid Driver/Voltage Regulator A3
AS-2518-22
MPU A4
AS-2962-7
Transformer
&
Rectifier A2
AS-2877-3
Rectifier Board (Part of A2)
AS-2518-49
Sound
AS-2888-3
Auxiliary Lamp Driver A9
AS-2518-43
REPAIRS PROCEDURES/AIDS
Module
&
Component Replacement
F.O. 560-1
AID (Assistance in Diagnostics)
Kit, used with F.O. 560-1
KIT #485-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module repair.)
Kit #490-For Rectifier Board (Part of A2)
Kit #503-For MPU Board A4 (Less Memory U1-U6)
Kit #492-For Solenoid Driver/Voltage Regulator A3
Kit #493-For Display Driver A1
Kit #494-For Lamp Driver A5
Kit #518-For Sound A8
20
