GAME #1152·E KISS SOLENOID IDENTIFICATION TABLE
SELF-
SELF-
TEST
#
SOLENOID IDENTIFICATION
TEST
#
SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
07 TOP THUMPER BUMPER
02 KNOCKER
08
LEFT SLINGSHOT
03 DROP TARGET RESET
09 RIGHT SLINGSHOT
04 LEFT THUMPER BUMPER
10 RIGHT BOTTOM GATE
05
RIGHT THUMPER BUMPER
11 COIN LOCKOUT DOOR
06
BOTTOM THUMPER BUMPER
12
K1 RELAY (FLIPPER ENABLE)
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
SELF-
SELF-
TEST
#
DESCRIPTION
TEST# DESCRIPTION
01
DROP TARGET D (BOTTOM)
21 OUTER'S'
ROLLOVER
02
DROP TARGET C
22 INNER'S'
ROLLOVER
03 DROP TARGET B
23 'I' ROLLOVER
04
DROP TARGET A (TOP)
24 'K'ROLLOVER
05 LlTE-A-LiNE 5,000 ROLLOVER
25 DROP TARGET AND 2 REBS.
06 CREDIT BUTTON
26 RIGHT FLIP/FEED LANE
07 TILT (3)
27 LEFT FLIP/FEED LANE
08 OUT HOLE
28
09 COIN III (RIGHT)
29
10 COIN I (LEFT)
~O
RIGHT SPINNER
11
COIN II (MIDDLE)
31 LEFT SPINNER
12 'D'TARGET
32
13 'C'TARGET
33 RIGHTOUTLANE
14 'B'TARGET
34 LEFT OUTLANE
15 'P\ TARGET
35 RIGHT SLINGSHOT
16 SLAM (2)
36 LEFT SLINGSHOT
17 LOWER'S'TARGET
37 BOTTOM THUMPER BUMPER
18 UPPER'S'TARGET
38 TOP THUMPER BUMPER
19 TTARGET
39 RIGHT THUMPER BUMPER
20 'K'TARGET
40 LEFT THUMPER BUMPER
NOTE:
SLINGSHOT AND THUMPER
BUMPER COILS WILL ENERGIZE
WHEN SWITCH IS MADE.
