PARTS LIST
DRAWING
PART
DESIGNATION
NUMBER
DESCRIPTION
IC-2001-152-B BARE P.C. BOARD
IC9,IC10,ICll
5310-08971-00 MC 14069 HEX. INVERTER
IC3, IC4
5310-08970-00 MC 14543 BCD TO SEVEN SEGMENT
LATCH/DECODER/DRIVER
IC1, IC2
5680-08969-00 UDN 7180 GAS DISCHARGE
IC7, IC8
5680-08968-00 UDN-6184A OR UDN-6118A GAS
DISCHARGE DISPLAY SEGMENT DR.
IC14
5310-09450-00 MC 14081 QUAD 2-INPUT AND GATE
\
ZR1
5075-09135-00 1N4740A ZE~R DIODE 10V, 5% 1W
C1,C2
5043-08980-00 CAPACITOR CERAMIC, .01 MFD, 50V
C5 THRU C8
R1-R14
5010-08981-00 RESISTOR,FC,10K OHM, 10% 1/2 WATT
R15, R16
5010-09149-00 RESISTOR, 15K OHM, 10% 1/2 WATT
R17
5010-09086-00 RESISTOR, FC, 6.8K OHM 10%, 1/4 WATT
R18 THRU R27
5010-08982-00 RESISTOR, FC, 3 MEG OHM, 10% 1/4 WATT
WI, W3
5010-09534-00 RESISTOR, FC, 0 OHM, 1/4W
J1 THRU J4, J8
5791-09347-00 20 PIN RIBBON HEADER
7
