Page 87 - Judge Dredd (Bally)

A-16765 Outhole Ball Trough Assembly
17
16
I
I I
I
I I
I I
I I
_j I
I
I
5
~-- -- -- , , -
Item Part Number Description Item Part Number Description
A-16809 Ball Trough Welded Assy 10. 01-11586 Call Mtg. Bracket (l3ell)
? 01~11587 Ball Trough Front 11. 4008-01017-05 Mach. Screw, S 32x5!1 G 1)-1\II '; ! I.h
:l 1\ 6306 2 Bell Armature Asssembly 12~ 4408-0111900 Nut 8-32 ESN
, ) AE -26 -1500 Coil Assembly 13. 4008-0101706 Mach Screw, 8-32x3/o P-Hi I ~:l r.l.~:
~ 01 8508-T Solenoid Bracket 14~ 23-6702 Bumper Plug
G 03-7067 5 Coil Tubing 15. A-16529 7 IR LED PCB Assembly
10-135 Insulator 16. A-16530 7 IR LED PCB Assembly
8. 23-6420 Rubber Grommet 17. 4006-01017-06 Mach. screw, 6-32x3/S PHil SLMS
9 03-8523 Insulator
Judge Dredd 2-19
