A-16478 Planet Assembly
-----~----------------
----~
I'layfieid shown for reference only
~------------------
II
II
IL
_
7
Item Part Number
Description
Item Part Number
Description
14-7985
Motor, 12VDC
11.
4702-00023-00
Lockwasher, 3/4" Internal
2.
H-16961
Cable Assembly
12.
02-4777
Nut 1/2-27
3.
A-16598
Planet Opto PC Board
13.
03-8858
Planet
4
4008-01017-08
Mach. Screw, #8 x 1/2"
14.
4702-00019-00
Lockwasher, 1/2"
IrllHrl~li
::_,
A-16808
Bracket Assembly
15.
A-16475
Light Assembly
G.
4008-01017-06
Mach. Screw, #8 x 3/8"
16.
H-16901
Cable Assembly
I
03-8869
Interrupter
17.
02-4466-8
F-F Spacer 1/4 x 15/16" I lex.
8.
4008-01083-03
Set Screw, #8 x 1/8"
18.
A-16527
Bracket & Tube Assembly
9.
02-4776
Nut 3/4-16
19.
4008-01005-06
Sh. Metal Screw, 8-32 x 3/8" P-PH
10.
A-16336
Washer & Leg Assembly
20.
4408-01128-00
Nut 8-32 KEPS
Judge Dredd
2-27
