8-12665 Kicker Arm (Slingshot) Assembly
5c
I
I
I
:0
Associated Parts for
Right
&
Left Kickers:
Item Part Number
Description
Item Part Number
Description
1.
12-6227
Hairpin Clip
6.
A-14369-R
Coil
&
Bracket Assy., Right
2.
A-12664
Kicker Crank Assembly
A-14369-L
Coil
&
Bracket Assy., Left
3.
A-5653
Mounting Bracket Assembly
a) 8-7572-1
Bracket
&
Stop Assembly
4.
4700-00030-00 Flatwasher,
17/64
x
112
x 15ga.
b) 01-8-508-S
Coil Retaining Bracket
5.
A-5103
Coil Plunger Assembly
c) 4006-01017-06
Mach. Screw, 6-32 x
3/CJ
a) 022364
Coil Plunger
d) 4406-01119-00
Nut, 6-32 ESN
b) 03-8085
Armature Link
e) AE-27-1200
Coil Assembly
c) 20-8716-5
Roll Pin,
118
x
7/16"
f) 03-7066
Coil Tubing
7.
10-128
Spring
Judge Dredd 2-18
