Printed Circuit Boards
(Continued)
A-15646-2
24-Switch Opto PC Board
Part Number
53701089100
5490 10892-00
5431-10449 00
5192 13591 00
S04310893 00
S043 09065 00
5043 08996 00
S041-10588-00
S043-08980-00
S048-12577 00
5043 09845-00
SO70 09054 00
S040 10974-00
SO10 0899 7 00
50100916200
5010 09768 00
5010 09039 00
SO10-09324 00
5010 08930 00
5010 09034 00
5010 1002200
5010 08773 00
5010 09085 00
5671-13732-00
5791 12273 03
5791 12273 02
5791 12273 05
5551 10890 00
5010-09534-00
5010 09085 00
Description
U1
U2
U3
01
C3
C4, C12
C5, C11
C6
C8
C2
C1, C9
01 - 03
C7, C10
R1
R2, R6
R3
R4
R5
R7
R8
R10
R11
R13
LED1
J1
J2
J3
L1
R12
R9
Judge Dredd
Description
I.C, Opto Receiver, MC3373
I.C, Opto Isolator
I.C, 555 Timer
Trans, MPSA64 PNP Darlington
Capacitor,
co isuro.
50v Axial
Capacitor, 470PF, SOv(±20%) Ax,
Capacitor, 0, 1 ~IFD, SOv(±20%) Ax,
Capacitor, 6,8f,ltd, 25v (20%)
Capacitor, 01f,ltd, 50v (+80, 20%) Ax,
Capacitor, .47f,ltd SOvAxial
Capacitor,
ooturo.
50v (±20%) Ax,
Diode 1N4004 1,OA,
Capacitor, 100~ltd, 35v (+80,-20%)
Resistor, 2,7KU, 1I4w, 5%
Resistor, 100KU,
1/4w, 5%
Resistor, 180Kil,
1/4w, 5%
Resistor, 10KU,
1/4w, 5%
Resistor, 27Kil,
1/4w, 5%
Resistor,
470U, 1/4w, 5%
Resistor, 10KU,
1/4w, 5%
Resistor, 7,5Kil,
1/4w, 5%
Resistor, 18KU, 1I4w, 5%
Resistor, 1,5Kil, 1I4w, 5%
Display LED Red 1
Connector, 3 pin Header Str Sq Lck
Connector, 2-pin Header Str Sq Lck
Connector, 5-pin Header Str Sq Lck
Inductor, 1O~IH
Resistor,
Oil
(Jumper)
Resistor, 1 5KU, 1I4w, 5%
2-15
