13. Remove captive ball holders and packaging foam from the playfield.
14. Clean and reinstall the playfield cover glass, reversing the procedure of step 7.
15. To attach line cord, remove envelope stapled to the inside cabinet (near cashbox).
Remove the
four Phillips-head screws that mount the line cord cover plate to the rear cabinet. Match the prongs
on the plug with the holes in the receptacle and push line cord securely into place. Make sure cord
is aligned with the indentation of plate (indentation should point toward bottom of cabinet).
Remount line cord cover plate. If desired, tamper resistant screws have been provided in an
envelope marked "Security Screws" (located in cashbox) to remount cover plate. Prepare the
game for player operation.
LJ------'--
Line Cord
&
Plug
Tamper-resistant
Screw
Judge Dredd 1-4
