7 Ball Trough LED PCB Assembly
A-16927
7 Ball Trough LED PCB Assembly
Connector Wiring
J1-1
Gray-Yellow, +12V from Power Driver Board J11S-2
J1-2
N/C
J1-3
N/C
J1-4
Key
J1-5
Black, ground from Power Driver Board J118-3
7 Ball Trough Photo Transistor PCB Assembly
Connector Wiring
J1-1
Green-Gray, sw. col. 8 from CPU Board J207-9
J1-2
White-Red,
SW.
row 2 from CPU Board J209-2
J1-3
White-Brown,
SW.
row 1 from CPU Board J209-1
J1-4
White-Orange,
SW.
row 3 from CPU Board J209-3
J1-5
White-Violet,
SW.
row 7 from CPU Board J209-S
J1-6
White-Blue,
SW.
row 6 from CPU Board J209-7
J1-7
White-Yellow,
SW.
row 4 from CPU Board J209-4
J1-8
White-Green,
SW.
row 5 from CPU Board J209-5
J1-9
Key
J1-10
Black, ground from Power Driver Board J 118-3
J1-11
Gray-Yellow, +12v from Power Driver Board J 118-2
J1-12
Gray-Yellow, +12V from Power Driver Board J1-11
Judge Dredd 3-17
RS
R7
R6
R5
R4
R3
R2
R1
1.2K
270
270
270
270
270
270
270
GND 3
LED S
LED 7
LED6
LED 5
LED4
LED3
LED 1
KEY 4
GND 5
0
I
RS
LED
7
0
LED 1
I
I
LED 6
R3
LED 5
00
--LBD-
Rl
LED 3
OLED4
0
lourwB
0
\
R2
I
\
R4
LED 2
