5-8ank Opta Assembly
A-16486
Jl
I OPT01 \
\OPT02\
IOPT03\
IOPT04\
IOPTOS\
J1 - 1 White-Gray, from J209-9
J1 - 2 White-Violet, from J209-8
J1 - 3 White-Blue, from J209-7
J1 - 4 White-Green, from J209-5
J1 - 5 White-Yellow, from J209-4
J1 - 6 Green-Black, from J207-5
J1 - 7 Key
J1 - 8 Gray-Yellow, +12VDC from J 118-2
J 1 - 9 Black, Ground from J 118-3
+12
J1
8
KEY
7
R5 1
R4
2 R3 3 R2
4
R6
1.2K RS
R4
R3
R2
R1
1/4W 4701/2W
4701/2W
4701/2W
4701/2W
4701/2W
R1
01
1N4004
Judge Dredd 3-15
