SOLENOID/FLASHER LOCATIONS
CQlllElllbl[
Aillmbill
.111m
Number
Number
Description
01 A-12158-1
A-16769
Globe Magnet
02 AE-26-1200 A-16580
Left Popper
03 AE-23-800
A-15769
Right Popper
04 14-7989
A-16678
Globe Arm
05 AE-24-900
A-16947
tReset Drop Targets
06 14-7985
A-16478
tGlobe Motor
07 AE-23-800
B-1~1
"Knocker
08 AE-23-800
A-14525
Right Shooter
09 AE-23-800
A-16936
Left Shooter
10 AE-27-1200 A-16445
tTrip Drop Target
11 AE-25-1000 A-16802
tDiverter
12
Not Used
13 AE-26-1500 A-16765
Trough
14
Not Used
15 AE-27-1200 A-14369-L Left Slingshot
16 AE-27-1200 A-14369-R Right Slingshot
17
24-8802
A-16844
Judge Fire Flashers (2)
18
24-8802
A-16844
Judge Fear Flashers (2)
19
24-8802
A-16844
Judge Death Flashers (2)
20 24-8802
A-16844
Judge Mortis Flashers (2)
21 24-8802
A-12336-1 Pursuit Left Flashers (3)
22 24-8802
A-12336-1 Pursuit Right Flashers (3)
23 24-8802
A-16929
Blackout Flashers (3)
24 24-8802
tA-16891
Cursed Earth Flashers (2)
25 24-8704
A-8798
Lower Left Flashers (4)
24-8802
26 24-8802
A-16475
tGlobe Flashers (3)
27 24-8704
A-8798
Right Ramp Flashers (3)
24-8802
28 24-8802
"Insert Flashers (3)
Glnlrlllllumination
Cj[cujts
"01 String 1 24-6549,24-8768
GI String 1
"02 String 2 24-8768
GI String 2
"03 String 3 24-6549,24-8768
GI String 3
'04
String 4 24-8768
GI String 4
"05 String 5 24-8768
GI String 5
Fllppl[ Colis
Assemblll
"FL-11629 (Blue) A-15205-L-2 Lower Left Flipper
"FL-11629 (Blue) A-15205-R-2 Lower Right Flipper
"FI_-11629 (Blue) A-16976-L
Upper Left Flipper
"FL-11630 (Red) A-15205-R Upper Right Flipper
"Not Shown
tLocated Under Playfield
• Square Indicates coil, P_C_B. or Magnet
• Circle Indicates flasher
Judge Dredd 2-45
