SWITCH LOCATIONS Continued
llim
SWitch part
#
Where Used
51
SW-1A-114
Left Sling (Kicker)
SW-1A-120
(Score)
52
SW-1A-114
Right Sling (Kicker)
SW-1A-120
(Score)
53
5647 -12693-19
Captive Ball 2
54
A-16486
Drop Target 'J'
55
A-16486
Drop Target 'U'
56
A-16486
Drop Target '0'
57
A-16486
Drop Target 'G'
58
A-16486
Drop Target 'E'
61
A-16598
'Globe Position #1
62
A-14231 (LED)
Left Ramp Enter
A-14232 (Trans.)
63
A-14231 (LED)
Left Ramp To Lock
A-14232 (Trans.)
64
A-14231 (LED)
Left Ramp Exit
A-14232 (Trans.)
65
Not Used
66
A-14231 (LED)
Center Ramp Exit
A-14232 (Trans.)
67
A-14231 (LED)
Left Ramp Enter
A-14232 (Trans.)
68
A-14227-15
Captive Ball 3
71
A-14231 (LED)
tMagnet Over Ring
A-14232 (Trans.)
72
A-14231 (LED)
Top Right Opto
A-14232 (Trans.)
73
A-14231 (LED)
Left Popper
A-14232 (Trans.)
74
A-14231 (LED)
Right Popper
A-14232 (Trans.)
75
A-14231 (LED)
Top Ramp Exit
A-14232 (Trans.)
76
A-14231 (LED)
Right Ramp Exit
A-14232 (Trans.)
77
A-16598
'Globe Position #2
78
Not Used
81
A-16926 (Trans.)
Trough 1
A-16927 (LED)
82
A-16926 (Trans.)
Trough 2
A-16927 (LED)
83
A-16926 (Trans.)
Trough 3
A-16927 (LED)
84
A-16926 (Trans.)
Trough 4
A-16927 (LED)
85
A-16926 (Trans.)
Trough 5
A-16927 (LED)
~
86
A-16926 (Trans.)
Trough 6
A-16927 (LED)
87
A-16926 (Trans.)
Top Trough
A-16927 (LED)
88
Not Used
• Not Shown
e
t
Located Under Playfield
~
Judge Dredd 2-43
