A-17811
Kicker Arm (Slingshot) Assembly
Associated Parts for Right
&
Left Kickers:
Item Part Number
Description
Item Part Number
Description
1 02-2364
Coil Plunger
8
B-9362-L-2
Coil
&
Bracket Assembly
2 A-17810
Mounting Bracket Assembly
a) A-17808
Bracket
&
Stop Assembly
3 A-12664
Kicker Crank Assembly
b) 01-8-508-5
Coil Retaining Bracket
4 12-6227
Hairpin Clip
c) 4006-01017-06 Mach. Screw, 6-32 x 3/8"
5 4700-00030-00 FW, 17/64 x
1/2
x 15ga.
d)
4406-01119-00 Nut, 6-32 ESN
6 03-8085
Armature Link
e) AE-26-1200
Coil Assembly
7 20-8716-5
Roll Pin, 1/8 x
7116"
f)
03-7066
Coil Tubing
9 10-128
Spring
2-16
