T.17 Visor Test
Once the test name is shown under the Test Menu, press the Enter button. The bottom line of
the display will show the state of the Visor Open and Visor Closed switches. An 'X' in the box
indicates the switch is closed.
This test has three modes of operation:
Open • Open the Visor: Run the visor motor until the Visor Open switch is closed.
Close·
Close the Visor: Run the visor motor until the Visor Closed switch is closed.
Cycle • Run the visor motor continuously.
The Up and Down changes the test mode. Pressing Enter changes the test between RUNNING
and STOPPED. When STOPPED, the motor will be turned off and the current test halted.
Press Escape to return to the Test Menu at any time.
T.18 Empty
Balls
This test checks the poppers and kickers that are under the playfield.
Press the enter button and all balls loaded into the poppers and troughs should be kicked out
until no balls remain in these locations. Any other result indicates a problem.
Note:
As
the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order
to
allow further balls to be kicked out.
,--...._
1-20
