MENU SYSTEM OPERATION
The Main Menu allows you to choose from several categories, which in tum lead to other menus to choose from. To
access the Main Menu, open the coin door and press the Begin Test button, then press the Enter button. Press the
Up or Down buttons to cycle through the Main Menu. Press the Enter button to access a menu. Press the Escape
button to return to the Main Menu. Press the Start button for HELP at any time.
MAIN MENU
B BOOKKEEPING MENU
B.1 Main Audits
B.2 Earning Audits
B.3 Standard Audits
B.4 Feature Audits
B.5 Histograms
B.6 TIme-Stamps
P. PRINTOUTS MENU
P.1 Earnings Data
P.2 Main Audits
P.3 Standard Audits
P.4 FeatureAudits
P.5 Score Histograms
P.6 TIme Histoarams
P.7 TIme-Stamps
P.8 All Data
T. TESTMENU
T.1 Switch Eckles Test
T.2 Switch Levels Test
T.3 Single Switches Test
T.4 Solenoid Test
T.5 Flasher Test
T.6 General Illumination Test
T.7 Sound and Music Test
T.8 Single Lamp Test
T.9 All Lamps Test
T.10 Lamp and Flasher Test
T.11 DisDlavTest
T.12 F1iDDerCoil Test
T.13 Ordered Lamps Test
T.14 Lamp Row-Col
T.15 DIP Switch Test
T.16 Ramp Test
T.17 VisorTest
T.1S EmDtvBalls
U. UTILmES MENU
U.1 Clear Audits
U.2 Clear Coins
U.3 Reset H.S.T.D.
U.4 Set TIme and Date
U.5 Custom Message
U.6 Set Game
1.0.
U.7 Factory Adjustments
U.S Factory Resets
U.9 Presets
U.10 Clear Credits
U.11 Auto Bum-in
A. ADJUSTMENT MENU
A.1 Standard Adjustments
A.2 Feature Adiustments
A.3 Pricina Adiustments
A.4 H.S.T.D. Adjustments
A.5 Printer Adjustments
Press Escaoe
To move out of a menu selection.
Press Enter
To get into a menuselection.
Press Up
Increases sequence; Example A.1, A.2, A.3. A.4.
Press Down
Decreases sequence; Example A.4. A.3, A.2, A.1.
Use Up or Down to cycle through the
selections in a menu.
Use Escape and Enter to move into and out of the
selected menu.
1-8
