RAISING THE PLAYFIELD
&
CAUTION
Do not raise the playfield straight upl
This game uses a slide assembly to raise and lower the
playfield.
To raise the playfield.
1.Remove all the balls from the game.
Grasp
bottom arch and carefully lift up playfield only
high enough to clear safety brackets. Rear guide
legs should not hit wood guide rails, or be used to
slide out playfield.
Rear Guide Le
(2 used)
Wood Guide Roil
I
(2
used)
2.Pull the playfield out toward you until it stops (rest
position), and raise it approximately 3
6
•
Be sure
playfield is in locked position and does not slide
back into cabinet. If it does, repeat Step 2 before
proceeding to Step 3.
3. Rotate playfield to upright service position (lean
on backbox) by pulling toward you and up. Listen
for the sound of a click: this ensures locking and
pivoting sequence.
,
5. Push the playfield back into cabinet and into the
playing position.
Slide Mechanism
(2
used)
\---@
<,
~
To lower the playfield.
4. Rotate the playfield to the rest position.
This
unlocks the pivoting mechanism.
I
1-5
