Coin Door Interface Board
A·17051·1
-~
!!l
•
" 0
loooooo.ooooolliii!§]
100000000.001
1
J3
12'
J2
5 1
J1
,
<rID
<nID
<lID
<nO
a:::£j])
CUD
GLD
urn
(][I)
13
J5
,
1000.000000001
o :
o
o
o
o
o ~
•
o
o
o
o
-1
0
!!l
0
o
• 0
"
J6
1
10000000000000.01
J1-1 Orange-Gray, decl. switch row 8 form CPU J205-9
J1-2 Orange-Violet, decl. switch row 7 from CPU J205-8
J1-3 Orange-Blue, ded, switch row 6 from CPU J205-7
J1-4 Orange-Green, decl. switch row 5 from CPU J205-6
J1-5 Orange-Yellow, decI. switch row 4 from CPU J205-4
J 1-6 Orange-Black, decl. switch row 3 from CPU J205-3
J 1-7 Orange-RecI, decl. switch row 2 from CPU J2OS-2
J1-8 Orange-Brown, decl. switch row 1 from CPU J205-1
J1-9 Key
J1-10 Black, ground from CPU J205-10
J1-11 Orange-White, switch enable from CPU J205-12
J2-1 Black, ground from Power Driver Board J116-3
J2-2 Gray-Yellow, +12vac for Power Driver Board J116-2
J2-3 Violet, G.I. from Power Driver Board J119-3
J2-4 Key
J2-5 White-Violet, G.I. 6.8vac from Power Driver J119-1
J3-1 Green-Brown, switch column. 1 from CPU J212-1
J3-2 Green-Red, switch column 2 from CPU J212-2
J3-3 White-Brown, switch row 1 from CPU J212-4
J3-4 White-Red, switch row 2 from CPU J212-6
J3-5 White-Orange, switch row 3 from CPU J212-7
J3-6 White-Yellow, switch row 4 from CPU J212-8
J3-7 Key
J3-8 Yellow-Gray, lamp col. 8 from Power Driver J136-3
J3-9 Red-Blue, lamp row 6 from Power Driver J135-7
J3-10 Red-Violet, lamp row 7 from Power Driver J 135-8
J3-11 Red-Gray, lamp row 8 from Power Driver J135-9
J4- Not Used
J5-1 Violet, G.!. return to coin door
J5-2 White-Violet, G.I. 6.8vac to coin door
J5-3 Black, ground to coin door
J5-4 Orange-Brown, ded. switch row 1 to coin door
J5-5 Orange-Red, ded. switch row 2 to coin door
J5-6 Orange-Black, ded. switch row 3 to coin door
J5-7 Orange-Green, ded. switch row 5 to coin door
J5-8 Orange-Blue, ded. switch row 6 to coin door
J5-9 Orange-Violet, ded. switch row 7 to coin door
J5-10 Key
J5-11 Orange-Gray, ded. switch row 8 to coin door
J5-12 Green-Red, switch column 2 to coin door Slam Tilt
J5-13 White-Brown, switch row 1 to coin door Slam Tilt
J6- Not Used
J7-1 Yellow-Gray, lamp column 8 to cabinet
J7-2
N/C
J7-3 Red-Violet, lamp row 7 to cabinet
J7-4 RecI-Gray, lamp row 8 to cabinet
J7-5 Key
J7-6 Green-Brown, switch column 1 to cabinet
J7-7 Green-Red, switch column 2 to cabinet
J7-8 White-Orange, switch row 3 to cabinet
J7-9 N/C
J7-10 NlC
J7-11 White-Orange, switch row 3 to cabinet
J8-1 White, switch row to cabinet Slam Tilt
J8-2 Key
J8-3 Green, switch column to cabinet Slam Tilt
J9-1 White-Yellow, switch row 4 to Plumb Bob Tilt
J9-2 Key
J9-3 Green-Brown, switch column 1 to Plumb Bob Tilt
J9-4 White-Red, switch row 2 to Interlock Switch
J9-5 Green-Red, switch column 2 to Interlock Switch
3-22
