Motor EM. w/Brake Board Assembly
A-15340
I
L1
m
-[]]]-
~rn
I
01
I
CIJID
c....
I
I
L2
J2
~----~~--~~L~1rY~--~1
4.7MH
J1-1 Blue-Yellow, Visor Motor, solenoid28 drive, from Power Driver board J122-4
J1-2 Nle
J1-3 Gray-Yellow, +12V, from Power Driver board J118-2
J2-1 Red, to Visor Motor
J2-2 Black, from Visor Motor
POWER DRIVER
BOARD
J118
o
GRY-YEL,
+12V
J122
VISOR MOTOR CIRCUIT
3
VISOR
MOTOR
SOL. 28
MOTOR
EMI BOARD
FLiPTRONIC II
CPU
BOARD
BOARD
J903
J906
BLK-VIO,
VISOR CLOSED SW. (F5)
BLK-GRY,
VISOR OPEN SW. (F7)
ORANGE, GROUND
3-20
