7-0pto Switch Board and Bracket Assembly
A-15595
o
o
o
o
•
o
o
C-
o '"
o
o
o
o
o
o
o
o
o
o
•
o
o
o
-EiD-
~
~
-[§J-
--@]-
o
o
o
o
•
o
o
o
o
o
o
o
o
o
J1-1
J1-2
J1-3
J1-4
J1-5
J1-6
J1-7
J1-8
J1-9
J1-10
J2-1
J2-2
J2-3
J2-4
J2-5
J2-6
J2-7
J2-8
J2-9
J2-10
J3-1
J3-2
J3-3
J3-4
J3-5
J3-6
J3-7
J3-8
J3-9
')'l-.••
tI
J3-11
J3-12
N/C
N/C
Gray-Green, (LED 5), to Trough IR LED Trough board J1-3
Key
Gray-Black, (LED 4), to Trough IR LED Trough board J1-4
Gray-Orange, (LED 3), to Trough IR LED Trough board J1-5
Gray-Red, (LED 2), to Trough IR LED Trough board J1-6
Gray-Brown, (LED 1), to Trough IR LED Trough board J1-7
NlC
Black, Ground, to Trough IR LED Trough board J1-9
NlC
NlC
Orange-Green, (Photo Transistor 5), to Trough IR Photo Transistor Trough board J1-7
Orange-Yellow, (Photo Transistor 4), to Trough IR Photo Transistor Trough board J1-6
Orange-Black, (Photo Transistor 3), to Trough IR Photo Transistor Trough board
J
1-5
Orange-Red, (Photo Transistor 2), to Trough IR Photo Transistor Trough board J1-4
Orange-Brown, (Photo Transistor 1), to Trough IR Photo Transistor Trough board J 1-3
Key
N/C
Gray-Yellow, +12V, to Trough IR Photo Transistor Trough board J1-1
NlC
Gray-Yellow, +12V, from Power Driver board J118-2
Black, Ground, from Power Driver board J118-3
Key
White-Brown, switch row 1, from CPU board J209-1
White-Red, switch row 2, from CPU board J209-2
White-Orange, switch row 3, from CPU board J209-3
White-Yellow, switch row 4, from CPU board J209-4
White-Green, switch row 5, from CPU board J209-5
we
N/C
Green-Orange, switch column 3, from CPU board J207-3
3-18
