Lower Playfield Parts
Item Part Number Description
1 01-9211
Plfd. Hanger Bracket Assy. (2)
2 01-11781
Leg Support (2)
3 A-19963
Outhole Ball Trough Assembly
4 A-15595
7-Switch Opto PCB
&
Bracket
5 A-17811
Kicker Arm (Slingshot) Assy.
B-9362-L-2
Coil
&
Bracket Assembly (2)
6 A-20125
5-Lamp PCB Assembly
7 A-9415-2
Jet Bumper Coil Assembly (3)
B-9414-3
Jet Bumper Assembly (3)
8 A-15340
Motor EMI w/Brake Assembly
9 A-1n49.1-2
Slide Playfield Assembly, R.
10 C-11159
Visor Assembly
11 A-20453
Eject Assembly (3)
12 A-1n49.1-2
Slide Playfield Assembly, L.
13 A-20174
4-Lamp PCB Assembly
14 C-11157
Moving Target Assembly
15 A-20100
Motor Bracket Assembly
16 B-11304
Ramp Lifting Mech. Assembly
17 A-20079
3O-Lamp PCB Assembly
18 A-16032-1
3-Bank Drop Target Assembly
19 A-20158
Single Flashlamp Assy. (3)
20 A-15849-L
Flipper Assembly, Lwr. Left
21 A-15849-R Flipper Assembly, Upr. Right
~
