DRIVER BOARD
2P1 • INTERBOARD CONNECTOR
2P2 • SWITCH STROBE DRIVE
2P5 • LAMP COLUMN DRIVE
Pin
Wire Color
Function
Pin
Wire Color
Function
1
N/C
Not Used
1
Yellow- Violet
Lamp Column # 7
2
N/C
Not Used
2
Yellow-Gray
Lamp Column # 8
3
N/C
Not Used
3
Yellow-Green
Lamp Column # 5
4
Key
Key
4
Key
Key
5
Green-Black
Switch Strobe # 5
5
Yellow-Blue
Lamp Column # 6
6
Green- Yellow
Switch Strobe # 4
6
Yellow-Orange
Lamp Column # 3
7
Green-Orange
Switch Strobe # 3
7
Yellow- Black
Lamp Column # 4
8
Green-Red
Switch Strobe # 2
8
N/C
Not Used
9
Green-Brown
Switch Strobe # 1
9
Yellow-Red
Lamp Column # 2
2P3 • SWITCH ROW INPUTS
2P6 • LAMP GROUNDS
Pin
Wire Color
Function
Pin
Wire Color
Function
1
White-Gray
Switch Return # 8
1
Black
Lamp Ground
2
Key
Key
2
Key
Key
3
White- Violet
Switch Return # 7
3
Black
Lamp Ground
4
White-Blue
Switch Return # 6
4
Black
Lamp Ground
5
White-Green
Switch Return # 5
5
N/C
Not Used
6
White- Yellow
Switch Return # 4
6
Black
Lamp Ground
7
White-Orange
Switch Return # 3
7
Black
Lamp Ground
8
White-Red
Switch Return # 2
8
Black
Lamp Ground
9
White-Brown
Switch Return # I
9
Black
Lamp Ground
2P4 • LAMP POWER BUS
2P7 • LAMP ROW DRIVE
Pin
Wire Color
Function
Pin
Wire Color
Function
1
Blue
LampB+
I
Red-Brown
Lamp Row# 1
2
Blue
LampB+
2
Red-Black
Lamp Row # 2
3
Key
Key
3
Red-Orange
Lamp Row# 3
4
Blue
LampB+
4
Red-Yellow
LampRow# 4
5
Blue
LampB+
5
Red-Green
Lamp Row # 5
6
N/C
Not Used
6
Red-Blue
Lamp Row # 6
7
Blue
LampB+
7
Key
Key
8
Blue
LampB+
8
Red-Gray
Lamp Row # 8
9
Blue
LampB+
9
Red-Violet
Lamp Row # 7
