GAME ADJUSTMENT PROCEDURE
Adjustment Items 01 through 70
The coin door must be open to access the Game Adjustment/Diagnostic switches. All readings and adjustments
require operation of these coin door switches. Some adjustments utilize the Credit button; some also use the
flipper button(s). Additional text describing the game adjustment items follows this procedure.
1. Use AUTO-UP and press ADVANCE. The Credits display indicates Ad. The BALL IN PLAY/MATCH
display initially indicates 01. The SPEEDER 1 and SPEEDER 2 player score displays indicate AUTO
REPLAY. The SPEEDER 3 display shows PERCENT. If the factory setting has not been changed, the
SPEEDER 4 display shows 10, indicating the setting of a 10% replay percentage.
2. To reach a higher item number (in the BALL IN PLAY/MATCH display), use AUTO-UP and press AD-
VANCE. To return to a previous item number, use MANUAL-DOWN and press ADVANCE.
3. With the desired item number (refer to the
HIGH SPEED Game Adjustment Table)
showing in the
BALL IN PLAY/MATCH display, increase the value shown in the SPEEDER 4 display by using AUTO-UP
and pressing the Credit button. Repeat this step for each item, until all adjustments have been made.
For example, the operator may desire to zero the values associated with certain items listed in the
HIGH SPEED Audit Table.
To zero the first four items (concerning the coin chutes and the total
coins), the operator can proceed to item 68, Clear Coins, and press the Credit button to obtain the YES
option. The operator then presses the ADVANCE button and notes the "COINS CLEARED" display,
which verifies that the entry values for items 01 through 04 of the Audit Items are now reset to zero.
4. To proceed through the entire adjustments series, press
and hold
ADVANCE, until item 70 shows in the
BALL IN PLAY/MATCH display. From item 70, you can: (A) return to the Game-Over Mode; (B) restore
factory settings and zero audit (bookkeeping) totals. Perform either of the following, as desired:
•
A. To reach Game-Oyer Mode, use AUTO-UP and press ADVANCE once.
HIGH SPEED
now goes to
the Game-Oyer Mode.
B. To restore factory settings, zero all audit (bookkeeping) totals,
and
return to Game-Oyer Mode, use
AUTO-UP or MANUAL-DOWN to display item 70 in the BALL IN PLAY/MATCH display. Press the
Credit button to display the YES option in the SPEEDER 4 display. Using AUTO-UP, press AD-
VANCE once.
HIGH
SPEED
now zeroes ALL audit totals and changes ALL game adjustments back
to those originally selected as Factory Settings. It then shows the operator a message ("FAC-
TORY SETTING") that this has occurred. (A problem in the Memory Protection circuit or closing the
coin door will cause the message "ADJUST FAILURE" to appear.) Press ADVANCE once more to
return to the Game-Oyer Mode.
Details of Adjustment Items 01 through 70
01 Auto Replay (or Fixed Replay)
Of the two options, AUTO REPLAY is the Factory Setting. The percentage of replays automatically award-
ed has a Factory Setting of 10
(%).
Use the Credit button to change the percentage within the range of 5 to
50
(%),
with the value increasing using AUTO-UP (or decreasing using MANUAL-DOWN). The next Credit
button change beyond 50, or below 5, selects the FIXED REPLAY option.
For AUTO REPLAY, Ad 02 provides the Starting Replay Level (SPEEDER 1 and 2 displays show REPLAY
START). Ad 03 provides the number of replay levels (01, 02, 03, or 04).
HIGH SPEED
then proceeds to
Ad 06 automatically.
For FIXED REPLAY, Ad 02 is the first replay level (REPLAY LEVEL 1). Ad 03, 04, and 05 are the other re-
play levels.
•
02 Starting Replay Level (or Replay Level 1)
For AUTO REPLAY (refer to Ad 01), the Factory Setting is 1,400,000. The range of settings is 800,000
through 2,000,000 (by increments of 100,000 with AUTO-UP or decrements of 100,000 with MANUAL-
DOWN).
For FIXED REPLAY, the operator can enter the value to be used for the first fixed replay score level via the
Credit button. The range of settings is: OFF; 100,000 through 9,900,000 (by increments of 100,000 with
