ASSEMBLY ADJUSTMENTS:
switch assemblies consist of leaf springs, contacts, separators, ptastic tubing and
II'r,clwc::;
to hold them to the mounting surface. Before attempting to adjust a switch
, make sure that these screws are tight. If not, tighten screw closest to the con-
end of the leaf spring first. This will prevent the assembly from being secured in such
manner that the leaf springs tend to fan out. In general, all leaf springs are adjusted for
1116"
gap
in the open position ana
.010"
overtravel or wipe in the closed position. All
"""""',.', ••should be in good condition. Unless otherwise instructed, they should be dry or
bricated. All contacts should be free of dust and dirt. Contacts, with the exception
the flipper button switch assemblies, are plated to resist corrosion. Filing or burnishing
ks
the finish and encourages corrosion. Clean by closing the contacts over a clean
of paper (e.g.
a
business card) and then pull the card out from between them, wip-
them clean.
parts catalogue is available upon request. The catalogue is illustrated and lists all
ment parts for each game manufactured by Bally/Midway. Requests should be
sed to:
.•
BALLY/MIDWAY MFG. CO.
10601 W. BELMONT AVE.
FRANKLIN PARK, IL. 60131
ATTN: PARTS DEPARTMENT
HINTS:
Bally/Midway playfield has an improved tuff-coat finish with excellent wearing pro-
ies. Its life expectancy, as well as play appeal, can be extended by periodic cleaning
the playfield .
. Bally/Midway recommends you clean your playfield with Wildcat #125 (Wildcat
hemical Co., 1333 W. Seminary Drive, Ft. Worth, Texas 76115). Wildcat #125 is a com-
nation cleaner and polish. Bally/Midway has tried and tested this product and found it
be very effective. If Wildcat #125 is not available, Bally/Midway suggests you ask your
stributor to order it. Inspect and hand polish the ball in a clean cloth. A chipped ball
ust be replaced. It can ruin the finish on the playfield in a short period of time.
'T: Use water in large quantities, highly caustic cleaners, abrasive cleaners or
-,.c.~ning pads on the playfield. Do not allow a wax or polish build up. Waxes yellow with
and spoil play appeal.
17
