Solenoids/ Flashers
Item Part No.
1 AE-23-800-01
2 AE-23-800-04
3 AE-23-800-04
4 AE-23-800-04
5 AE-23-800-03
6 #63 Flashlamps
7 #63 Flashlamps
8 AE-23-800-03
9 5580-09613-00
10 5580-09613-00
11 5580-09555-00
12 #63 Flashlamps
13 #63 Flashlamps
14 AE-23-800-02
15 SM-29-1000-DC
16 404603-2·
17 AE-23-800-03
i
8 AE-23-800-03
i
9 #63 Flashlamps
20 Not Used
21 Not Used
22 Not Used
- FL 24/600-
30/2600-50VDC
FL 23/600-
30/2600-50VDC
- FL 24/600-
30/2600-50VDC
- FL 23/600-
30/2600-50VDC
.• - Cainca pin
Description
Trough Kicker (Outhole)
3-Bank Raise
4-Bank Raise 1 (left 2)
4-Bank Raise
i
(right 2)
Lockup Eject (Multi-ball)
Lockup Flasher
Left Magnet Flasher
Ball Feed
Left Magnet Relay
Right Magnet Relay
General Illumination Relay
3-Bank Flasher
Eyes (Backbox
&
Head)
Credit Knocker
8ell
Coin-Lockout Relay
Left Kicker
Right Kicker
Right Magnet Flasher
Upper Right Flipper
Right Flipper
Upper Left Flipper
Left Flipper
Rubber Parts
Item Part No.
Description
A 23-6300
5/16" Ring
B 23-6301
3/4"
Ring
C 23-6304
1-1/2" Ring
0
23-6306
2-1/2"
Ring
E
23-6552
Sleeving
G 23-6535
Bumper
H
23-6580
Bumper
I
23-6519-4 Red Ring
J
23-6327
Ball Shooter Tip
K 23-6535
Bumper
GRAND LIZARD 46
