A-12842-2
Description
Jumper Bumper Assembly
GILLIGAN'S ISLAND 2-16
Item Part Number
1 AE-26-1200
a)
5070-09054-00
2 B-12749
3 03-8324-5
4 01-9166
5 01-9321
6 01-9319
7 01-9117
8 02-3406-1
9 4705-00002-00
10 01-9116
11 01-9.020
12 10-411
13 A-14271
a) 24-8768
b) 24-8813
14 Not Used
15 Not Used
16 03-8292-7
17 A-12854
18 03-6035-7
19 10-326
20 4408-01119-00
21 4406-01119-00
22 B-13267
a) SW-1A-187
b) 5070-06258-00
23 4008-01070-14
24 4005-01016-18B
25 4008-01015-04
26 4006-01015-06
27 4101.1-01001-10
*
28 03-7066
29 03-8291-9
30 4004-01003-08
31 03-6047-16
*
Not Shown.
Coil
&
Tubing Assy.
Diode 1N4004, 1.0A.
Core Plug
&
Bracket Assy.
Thunder Bumper Base, Wht.
Switch Plate
Switch Plate
Plunger Bracket
Mounting Bracket
Plunger Coil
Spring Washer, 1/2"
Bracket Plate
Plate, Bakelite
Compression Spring
Socket Assembly
Bulb #555 (6.3v., 0.25A.)
Lamp Socket
Body, Black
Flange & Stud Assembly
Wafer, White
Compression Spring
Nut, 8-32 ESN
Nut, 6-32 ESN
Switch
&
Diode Assembly
Switch
Diode, 1N4001, 1.0A.
Mach. Screw, 8-32 x 7/8
Mach. Screw, 5-40
x
1-1/8
TT, 8-32
x
1/4
TT, 8-32 x 3/8
Sh. Metal Screw, #8 x 5/8
Coil Tubing
Thumper Bumper Cap, Red
Mach. Screw, 4-40 x 1/2
Tubing
