LED List
019 020 021
o
0 0
CPU Board
CPU Board
D19 , Blanking
D20, Diagnostic
D21, +Svdc
At game Turn-On
=
D19 & D21 On, D20 Off
During Normal Operation
=
D19 Off, D20 Flashing, D21 On
LED71~
I
o
LE03
00
LE02
LE06
LE04
0
o
LED 1
II
F11sll
o
Power Driver Board
II
F107111F10911
II
F106111F110ll
Power Driver Board
LED 1, +12vdc Switch Circuit, Normally On
LED 2, HighlLow Line Voltage Sensor, Normally On
LED 3, HighlLow Line Voltage Sensor, Normally Off
LED
4,
+5vdc, Digital Circuit, Normally On
LED 5, +20vdc, Flashlamp Circuit, Normally On
LED 6, +18vdc, Lamps Circuit, Normally On
LED 7, +12vdc, Power Circuit (motors relays etc.), Normally On
GILLIGAN'S ISLAND 1-44
LEOS
o
II
F1111
II
F1121
II
F1131
II
F1141
