PINBALL
GAME ASSEMBLY INSTRUCTIONS
1. Open the shipping container; remove all cartons, parts, and other items, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts are
providedamong the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts. See Figure 3 for details.
C-10643
Leg
08-7377
It---fl- Leg Leveler
See
OetaUVlew
Detail View of Leg Leveler
Figure 3. Pinball Assembly, Playfield Pitch Angle, and Leg Leveler Details.
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are free to move (not
kinked or pinched). Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position. Unlock the backbox, and remove the
backglass, storing it carefully to avoid scratches. Remove the shipping block holding the Insert Board.
Unlatch and open the Insert Board. This allows access to the bolt holes used for securing the backbox
upright. Install the washer-head mounting bolts through the bottom holes of the backbox into the
threaded fasteners in the cabinet to secure the backbox. Close the Insert Board and latch it in position.
Reinstall the backglass, and lock the backbox.
FAILURE TO INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect.
Always
lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage and
possible personal injury.
6. Extend each leg leveler
slightly
belowthe leg bottom, so that all four foot pads are extended about the
same distance. Removethe cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Locate the Molding Latch Lever, and move the lever toward the left
side of the game, to release the Front Molding. Lift the Front Molding off the playfield cover glass
GILLIGAN'S ISLAND 1-5
