CONNECTOR
&
COMPONENT IDENTIFICATION
I
Since
GILLIGAN'S ISLAND
uses WILLIAMS ELECTRONICS GAMES, INC. WPC Electronics
System, a new technique to identify connectors and other game components must be introduced. Each
plug or jack receives a number that identifies the circuit board and position on that board that it
connects to. J-designations refer to the male part of a connector. P-designations refer to the female part
of a connector. For example, J101 designates jack 1 of board 1 (a Power Driver Board Board jack); P306
designates plug 6 of board 3 (a Display Driver Board plug). Identifying the specific pin number of a
connector involves a hyphen, which separates the pin number from the plug or jack designation. For
example, J101-3 refers to pin 3 ofjack 1 on board 1.
f
t
Other game components may also have similar numbers to clarify their locations or related circuit.
For example, F501 refers to a fuse located on the Sound Board.
Prefix numbers for the WPC circuit boards are listed below.
1- Power Driver Board
2- CPU Board
5- Sound Board
6- Dot Matrix Controller
Dot Matrix DisplaylDriver Board
CmcUIT BOARDS
WPC Circuit Boards for
GILLIGAN'S ISLAND
are in the backbox. They are accessible by unlocking
the Backbox, removing the Backglass, unlatching the Insert Board, and swinging it open.
Lamp circuit boards are mounted under the Playfield.
PowerDriverBoard
The Power Driver Board is
pIn
A-12697.
CPU Board
The WPC CPU Board,
pIn
A-12742-20003,must be equipped with the ROMspecified in the
ROM Summary.
Sound Board
The Sound Board
pIn
A-12738-20003,must be equipped with the ROMs specified in the
ROM Summary.
Dot Matrix Conb-oller
The Dot Matrix Controller Board is pin A-14039.
Dot Matrix DisplaylDriver Board
The Dot Matrix DisplaylDriver Board is
pIn 5901-12784-00.
GILLIGAN'S ISLAND 1-2
