A-14147 Diverter Assembly
•
Associated Parts
Item Part Number
Description
Item Part Number Description
•
1 A-14146
Diverter Bracket Assy.
9
A-14185
Drive Arm Assembly
2 01-8413
Coil Mounting Bracket
a)
01-8456
Bracket
3 4701-00004-00 Lockwasher, #10 Split
b)
02-4504
Bushing Drive Hub
4 4010-01008-06 Mach. Screw, 10-32 x
3/8
10 A-14163
Shaft Assembly
5 03-7066
Coil Tubing
a)
02-4503
Shaft
6 AE-26-1200
Coil Assembly
b)
01-9908
Ball Guide
7 A-10821
Flipper Stop Bracket Assy.
c)
20-8712-25
"Eft-Ring Retainer
8 20-8790
Nylined Bearing
d)
07-6688-20
Rivet, 1W Lg.
11 A-13278
Plunger Assembly
'
.
•
2-25
Dlverter Assembly
