Head Assembly
2·22
A-13718 Head Assembly
•
Item Part Number
Description
Item Part Number
Description
A-13734
Bracket, Head Sub-Assembly
8 H-14252-2
Ramp Switch Cable
01-9674
Bracket
9 H-14252-3
Rudy Eye Cable
02-4454
Plunger Stop (2)
10 H-14252-4
Rudy Kicker Cable
02-4457
Shading Ring (2)
11 SM-30-1100-DC Coil Assembly (4)
02-4459
Jaw Pivot (2)
12 01-9676
Eye Bracket
02-4460
Crank Pivot
13 01-9959
Insulator (2)
20-9670
Standoff
6132
x 3/16 (4)
14 02-4455
Plunger
2 A-13735
Coil Bracket Assembly (3)
15 03-8424
Mandible
01-9677
Coil Mounting Bracket
16 03-8428
Crank
20-9496
Pem Nut 6-32 (2 each)
17 03-8468
Eye (2)
3 A-14026
Centering Bracket Assembly
18 03-8469
Eye Lids
01-9838
Centering Bracket
19 03-8486
Centering Flange
20-9496
Pem Nut 6-32 (2)
20 10-423
Extension Spring (2)
4 A-14027
Eye Bracket Assembly
21 10-424
Compression Spring (2)
01-9676
Eye Bracket
22 10-425
Spring Bar
20-9496
Pem Nut 6-32 (3)
23 11-975
Wood Head Base
5 A-14028
Plunger Assembly
24 12-6928
Wire Eye Link (2)
02-4492
Lid Latch Plunger
25 20-9668
Eyelet 1/8 x 1/4 (2)
03-8480
Plunger Extension
26 5647-12073-43
Mini Micro Switch
20-8716-16
Roll Pin 1/16 x 5/16
27 5070-06258-00
Diode, 1N4001 1.0A
6 A-14029
Stop Bracket Assembly
28 01-9785
Switch Mounting Bracket
01-9839
Stop Bracket
29 03-7520-2
Tie Wrap
•
02-4454
Plunger Stop
30 20-8790-1
Nyliner (2)
02-4457
Shading Ring
20-9496
Pem Nut 6-32 (2)
Related Assemblies:
7 A-14030
Main Lid Plunger Assembly
02-4491
Main Lid Plunger
31 A-13941
Ball Eject Assembly
02-4500
Extension Plunger
03-8479
Eye Lid Link
A-13270
Bell Armature Assembly
20-8716-1
Roll Pin
3132
x 1/2
A-11334
Ball Popper Arm Sub-Assy.
02-2963
Bell Arm Stop
02-4279
Armature
03-8362
Armature Extension
.,
20-8716-20
Roll Pin 1/8 x 3/8
A-13942
Bracket Assembly
AE-26-1500
Coil Assembly
01-9784
Coil Mounting Bracket
Hardware:
03-7067
Coil Tubing
10-135
Coil Plunger Spring
4008-01015-048
MS 8-32 x 1/4 P-PH-TT
23-6420
Rubber Grommet
4006-01017-06
MS 6-32 x 5/16 P-PH-S (19)
4408-01119-00
Nut 8-32 ESN
4408-01118-00
Nut 8-32 Tee 3/8 Long (5)
32 31-1588-50003-1 Screened Plastic Face
4700-00021-00
FW .203 x .437 x .032 (2)
33 31-1588~50003·2 Screened Plastic Head Back
20-8712-25
"E" Ring
1/4"
Shaft (2)
4700-00072-00
FW .265 x .500 x .032 (2)
•
